ARCTIC P14 PWM PST CO (black/black)
₱599.00
Quick Description
Fast Track Fulfillment
Zero Risk Guarantee
Uncapped Setup™
Do you have a physical store?
Do you have a physical store?
Uncapped PC is a fully online business, but we’re based in the Philippines and committed to fast, secure, and reliable service.
Do you offer warranty?
Yes, we offer warranty coverage depending on the item. Warranty terms are stated on each product listing.
If you have questions about a specific item’s warranty, feel free to reach out before ordering.
How can I track my order?
Once your item has been shipped, we’ll send you a booking link from the courier we used, along with a tracking number and contact info for follow-ups.
You’ll be able to track your order in real-time and know exactly when to expect it.
Save more with bundled shopping
Product Description
The P14 PWM PST CO is a pressure-optimised 140 mm Fan for Continuous Operation
Optimised for Static Pressure
During the development of the new P14 PWM PST CO, special emphasis was placed on a focused airstream and thus a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Therefore, the P14 PWM PST CO is particularly suitable for use on heatsinks and radiators.
More Efficient Technology
The motor is powered by a PWM IC of the newest generation, which allows the new P14 PWM PST CO to run much more efficiently than its predecessors. This saves energy without compromising the performance.
For Continuous Operation
The premium quality of the dual ball bearing allows 24/7 continuous operation without compromising performance. Contamination and high temperatures affect this bearing much less than ordinary sleeve or ball bearings. Therefore, the dual ball bearing is the perfect choice if you want to ensure continuous operation at maximum speed. Please note that ball bearings have a physically higher bearing noise compared to conventional sleeve bearings.
Maximum Quietness, Minimum Vibration
Even at low speeds, the operating sound of the new ARCTIC motor is barely noticeable. Due to sinus-magnetizing the new motor only creates about 5 % of the vibration from the commutation of a regular DC motor without a filter. Consequently, there is no need for rubber spacers due to the steady and smooth torque of the new motor.
Extended Life Span
A 10 °C lower motor temperature roughly doubles the life span of a fan. The new ARCTIC motor has a four times longer service life through its low coil temperature. Consequently, we give a manufacturer warranty of 6 years.
200 to 1700 rpm Regulated via PWM
With a wide range of regulation and the PWM Sharing Technology (PST), the P14 PWM PST CO fan speed can be controlled synchronously with all your other fans together. This keeps noise at a minimum while guaranteeing maximum cooling performance when needed.
Two Way Installation
- Push warm air out of the case
- Pull cool air into your case
Technical Specifications
- Fan Speed: 200—1700 rpm PWM Controlled (0 rpm below 5 % PWM)
- Airflow: 72.80 cfm | 123.76 m³/h
- Static Pressure: 2.40 mmH 2 O
- Noise Level: 0.3 Sone
- Operating Ambient Temperature: 0—40 °C
- Warranty: 6 Years
- Fan Frame: Standard
- Control Type: PWM PST
- Connector: 4-Pin Connector + 4-Pin Socket
- Fan Bearing: Dual Ball Bearing
- Typical Voltage: 12 V DC
- Starting Voltage: 3.9 V
- Current | Voltage: 0.12 A | 12 V DC
- Cable Length: 400 mm
- Length: 140 mm
- Width: 140 mm
- Height: 27 mm
- Weight: 194 g
